Features
- Inductive measuring system incorporated directly into frame
- Readings selectable down to 0.01
- Rugged, forged steel frame with heat insulators
- Measuring spindle mounted in extra long guideway with lever-controlled retraction
- Anvil spindle can easily be fine adjusted
- Measuring spindle and anvil spindle made of hardened stainlesssteel; measuring faces carbide-tipped
- Adjustable center stop for automatic alignment
- Extremely accurate due to the straight transfer of spindle movement to the inductive measuring system according to the Abbe principle
- Universally applicable and extremely versatile, each instrument spans a broad measuring range, within this range any dimension and fit can be very quickly and easily adjusted
- Maximum wear resistance due to non-contact positioning in conjunction with carbide-tipped measuring faces
- Constant measuring force as a result of built-in spring, thus eliminating user influence
- Without indicating instrument
